Technical Specifications
| Parameter |
Specification |
| MODEL NO. | AMC302 |
| GRINDING CAPACITY PER HRS | 30 TO 35 KG* |
| AUTOMATION GRADE | SEMI AUTOMATIC |
| MATERIAL | MS BODY |
| POWER SOURCE | ELECTRIC |
| VOLTAGE (V) | 415 |
| CURRENT (A) | 4.5 |
| CORROSION RESISTANCE | YES |
| POWER CONSUMPTION | 3.50KWH |
| MOTOR RPM | 1440 |
| BEATER(CUTTER) RPM | 3840 |
| FREQUENCY (HZ) | 50 |
| MOTOR TYPE | THREE PHASE |
| COATING | POWDER COATING |
| CHAMBER | DOUBLE CHAMBER |
| MACHINE DIMENSION INCH | L-51", W-20", H-44" |
| FRONT CHAMBER DIMENSION INCH | 10" Dia x 5.00" Depth |
| CYCLONE DIMENSION INCH | L-22", W-22", H-93" |
| CYCLONE MOTOR | 0.5 & 1 HP |
