Technical Specifications
| Parameter |
Specification |
| MODEL NO. | AMC1002 |
| GRINDING CAPACITY PER HRS | 80 TO 100 KG* |
| AUTOMATION GRADE | SEMI AUTOMATIC |
| MATERIAL | MS BODY |
| POWER SOURCE | ELECTRIC |
| VOLTAGE (V) | 415 |
| CURRENT (A) | 16 |
| CORROSION RESISTANCE | YES |
| POWER CONSUMPTION | 9.50KWH |
| MOTOR RPM | 1440 |
| BEATER(CUTTER) RPM | 3840 |
| FREQUENCY (HZ) | 50 |
| MOTOR TYPE | THREE PHASE |
| COATING | POWDER COATING |
| CHAMBER | DOUBLE CHAMBER |
| MACHINE DIMENSION INCH | L-63", W-24", H-50.6" |
| FRONT CHAMBER DIMENSION INCH | 14" Dia x 8.5" Depth |
| CYCLONE DIMENSION INCH | L-30", W-30", H-100" |
| CYCLONE MOTOR | 0.5 & 2 HP |
