Technical Specifications

Parameter	Specification
Model	AZ201A
Capacity	15-17 kg/hrs (depending on material)
Material	MS Body
Automation Grade	Automatic
Power	Electric
Voltage	220
Current	10
Power Consumption	1.50 KWH
Motor	2880 RPM
Motor Type	Single Phase
Coating	Powder Coating
Chamber	Double Chamber
Machine Dimension(inch)	L-30" W-17" H-44"
Chamber Dimension(inch)	10"Dia x 5"Depth
Back Chamber Dimension(inch)	6"Dia x 4"Depth
